$ 235


  • AXE7800 Tri-Band WiFi – 7800 Mbps tri-band WiFi for ultra-fast browsing, 8K streaming, online gaming, and large file downloading, all at the same time.
  • WiFi 6E Unleashed – The brand new 6 GHz band brings more bandwidth, faster speeds, and near-zero latency.
  • Ultra Connectivity – 1× 2.5 Gbps WAN/LAN port + 1× 1 Gbps WAN/LAN port + 3× Gigabit LAN ports and two USB ports ensure max flexibility and boosted throughput.
  • Cutting-Edge Processing – Armed with a 1.7 GHz Quad-Core CPU.
  • HomeShield – Customize your home network with enhanced security and control.*
  • OneMesh™  – Creates a Mesh network by connecting to a TP-Link OneMesh Extender for seamless whole-home coverage.
26-05-2023 9:09 AM

Model: Archer AXE95

TP-Link AXE7800 Tri-Band Wi-Fi 6E Router

  • AXE7800 Tri-Band WiFi – 7800 Mbps tri-band WiFi for ultra-fast browsing, 8K streaming, online gaming, and large file downloading, all at the same time.
  • WiFi 6E Unleashed – The brand new 6 GHz band brings more bandwidth, faster speeds, and near-zero latency.
  • Ultra Connectivity – 1× 2.5 Gbps WAN/LAN port + 1× 1 Gbps WAN/LAN port + 3× Gigabit LAN ports and two USB ports ensure max flexibility and boosted throughput.
  • Cutting-Edge Processing – Armed with a 1.7 GHz Quad-Core CPU.
  • HomeShield – Customize your home network with enhanced security and control.*
  • OneMesh™  – Creates a Mesh network by connecting to a TP-Link OneMesh Extender for seamless whole-home coverage.
  • Compatible with Alexa – Control your router via voice commands and make your life smarter and easier with Amazon Alexa.
  • Extensive Coverage – 8× antennas and Beamforming ensure broad coverage.
  • More Vents, Less Heat – Improved vents area unleashes the full power of the whole machine.

Specifications

WIRELESS
Standards IEEE 802.11ax 6 GHz, IEEE 802.11ax/ac/n/a 5 GHz, IEEE 802.11ax/n/b/g 2.4 GHz
WiFi Speeds AXE7800 6 GHz: 2402 Mbps (802.11ax) 5 GHz: 4802 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax)
WiFi Range 4 Bedroom Houses
8× Fixed High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission
WiFi Capacity Very High
Tri-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple clients Airtime Fairness Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 8 Streams Connect your devices to more bandwidth
Working Modes Router Mode Access Point Mode
SECURITY
Network Security SPI Firewall Access Control IP & MAC Binding Application Layer Gateway HomeShield Security
Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner
Guest Network 1× 6 GHz Guest Network, 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network
VPN Server OpenVPN Server PPTP VPN Server L2TP VPN Server
VPN Client Open VPN Client PPTP VPN Client L2TP VPN Client
WiFi Encryption WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x)
HARDWARE
Processor 1.7 GHz Quad-Core CPU
Ethernet Ports 1× 2.5 Gbps WAN/LAN Port 1× 1 Gbps WAN/LAN Port 3× 1 Gbps LAN Ports
USB Support 1× USB 3.0 Port 1× USB 2.0 Port Supported Partition Formats: NTFS, exFAT, HFS+, FAT32 Supported Functions: Apple Time Machine FTP Server Media Server Samba Server
Buttons Power On/Off Button Reset Button
Power 12 V ⎓ 3.3 A
SOFTWARE
Protocols IPv4 IPv6
Service Kits HomeShield Learn More>
OneMesh™ OneMesh™ Supported Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products. Learn More> All OneMesh Products>
Parental Controls HomeShield Parental Controls
Custom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports
WAN Types Dynamic IP Static IP PPPoE PPTP L2TP
Quality of Service QoS by Device
Cloud Service Auto Firmware Upgrade TP-Link ID DDNS
NAT Forwarding Port Forwarding Port Triggering DMZ UPnP Virtual Server
IPTV IGMP Proxy IGMP Snooping Bridge Tag VLAN
DHCP Address Reservation DHCP Client List Server
DDNS TP-Link NO-IP DynDNS
Management Tether App Webpage
OTHER
System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access)
Certifications FCC, RoHS
Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉) Operating Humidity: 10%~90% non-condensing
TEST DATA
WiFi Transmission Power FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz)
WiFi Reception Sensitivity 2.4 GHz: 11ax HE20 MCS0:-95dBm, 11ax HE20 MCS11:-64dBm 11ax HE40 MCS0:-92dBm, 11ax HE40 MCS11:-62dBm 5 GHz: 11ax HE20 MCS0:-94dBm, 11ax HE20 MCS11:-63dBm 11ax HE40 MCS0:-91dBm, 11ax HE40 MCS11:-60dBm 11ax HE80 MCS0:-88dBm, 11ax HE80 MCS11:-57dBm 11ax HE160 MCS0:-85dBm, 11ax HE160 MCS11:-54dBm 6 GHz: 11ax HE20 MCS0:-93dBm, 11ax HE20 MCS11:-62dBm 11ax HE40 MCS0:-90dBm, 11ax HE40 MCS11:-59dBm 11ax HE80 MCS0:-87dBm, 11ax HE80 MCS11:-56dBm 11ax HE160 MCS0:-84dBm, 11ax HE160 MCS11:-53dBm
PHYSICAL
Dimensions (W×D×H) 12.2 × 8.1 × 6.8 in (311 × 207 × 174 mm)
Package Contents Wi-Fi Router Archer AXE95 Power Adapter RJ45 Ethernet Cable Quick Installation Guide
