Description
Model: FC-198E
FC-198E Keypad Access Controller
FC-198E series password keyboard access controller is specially designed for electric door locks and total security systems. Today the product provides 5 door opening methods: Mifare card, button door opening, password opening door, card + password opening door, wireless remote control door opening, etc.
FC-198E respectively supports ID cards, HID cards, Mifare cards and other cards, and supports 1000 card data capacity (standard) or 21000 cards the data is dual-capacity, which can meet a variety of different capacity requirements.
Product Parameters
- Working Voltage: DC 9-13.8V
- Working Current: < 120mA
- Working Temperature: -0 β – +65 β
- Working Humidity: 10-90%
- Reading Speed: < 0.2 seconds
- Reading Distance: 0-80mm
- Control Output: Dry node relay output, max current is 5A
- User Capacity: 1000 (Can be extended to 21000 groups)
- External Wiegand: Supports 1 set of external WG card readers to realize entry and exit card reading verification.
- Remote Control: Support 315MHZ wireless remote controller
- Issuing Device: Keyboard, admin card
- Size: 117 x 117 x 20mm
