- Intel^® Z87

- Dual Channel DDR3/DDR3L memory technology - 4 x DDR3/DDR3L DIMM slots - Max. capacity of system memory: 32GB* - Supports Intel^® Extreme Memory Profile (XMP) 1.3 / 1.2 - Distortion-Free Slot

- 2 x 64Mb AMI UEFI Legal BIOS with Multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS) - Supports Secure Backup UEFI Technology - ACPI 1.1 Compliance Wake Up Events - SMBIOS 2.3.1 Support - CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjustment

- Supports Intel^® HD Graphics Built-in Visuals : Intel^® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® Insider™, Intel^® HD Graphics 4400/4600 - Pixel Shader 5.0, DirectX 11.1 - Max. shared memory 512MB* - Three graphics output options: DVI-I, HDMI and DisplayPort - Supports Triple Monitor - Supports HDMI Technology with max. resolution up to 4K x 2K (4096x2304) @ 24Hz - Supports DVI-I with max. resolution up to 1920x1200 @ 60Hz - Supports DisplayPort with max. resolution up to 4K x 2K (4096x2304) @ 24Hz - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI (Compliant HDMI monitor is required) - Supports HDCP function with DVI-I, HDMI and DisplayPort ports - Supports Full HD 1080p Blu-ray (BD) playback with DVI-I, HDMI and DisplayPort ports

- 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec) - Premium Blu-ray audio support - Supports Purity Sound™ - 115dB SNR DAC with differential amplifier - TI^® NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets) - Direct Drive Technology - EMI shielding cover - PCB isolate shielding - Supports DTS Connect

- Gigabit LAN 10/100/1000 Mb/s - 1 x Giga PHY Intel^® I217V, 1 x GigaLAN Intel^® I211AT - Supports Intel^® Remote Wake Technology (on Intel^® I217V) - Supports Wake-On-LAN - Supports Dual LAN with Teaming - Supports Energy Efficient Ethernet 802.3az - Supports PXE

- 3 x PCI Express 3.0 x16 slots (PCIE2/PCIE3/PCIE4: single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE3); triple at x8 (PCIE2) / x4 (PCIE3) / x4 (PCIE4)) - 1 x PCI Express 2.0 x1 slot - 1 x mini-PCI Express slot - 2 x PCI slots - Supports AMD Quad CrossFireX™, 3-Way CrossFireX™ and CrossFireX™ - Supports NVIDIA^® Quad SLI™ and SLI™

- 6 x SATA3 6.0 Gb/s connectors by Intel^® Z87, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel^® Rapid Storage Technology 12 and Intel^® Smart Response Technology), NCQ, AHCI and Hot Plug - 4 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug (SATA3_A4 connector is shared with the eSATA port) - 1 x eSATA connector by ASMedia ASM1061, supports NCQ, AHCI, Hot Plug and Port Multiplier

- 1 x IR header - 1 x COM Port header - 1 x Power LED header - 2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin) - 3 x Chassis Fan connectors (1 x 4-pin, 2 x 3-pin) - 1 x Power Fan connector (3-pin) - 1 x 24 pin ATX power connector - 1 x 8 pin 12V power connector (Hi-Density Power Connector) - 1 x SLI/XFire power connector - 1 x Front panel audio connector - 2 x USB 2.0 headers (support 4 USB 2.0 ports) - 1 x Vertical Type A USB 2.0 - 2 x USB 3.1 Gen1 headers (support 4 USB 3.1 Gen1 ports) - 1 x Dr. Debug with LED - 1 x Power Switch with LED - 1 x Reset Switch with LED

I/O Panel - 1 x PS/2 Mouse/Keyboard Port - 1 x DVI-I Port - 1 x HDMI-Out Port - 1 x HDMI-In Port - 1 x DisplayPort - 1 x Optical SPDIF Out Port - 1 x eSATA Connector - 2 x USB 2.0 Ports - 4 x USB 3.1 Gen1 Ports (ASMedia Hub) - 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) - 1 x Clear CMOS Switch - HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
