Description
Model: 7130-2D
2D Platform Barcode Scanner 7130-2D
- IMAGE SENSOR 640 * 480 CMOS
- LIGHT SOURCE 4PCS WHITE LED
- RESOLUTION 1D≥5mil 2D≥10mil
- DEPTH OF FIELD: EAN13, Code 39, QR Code
- SIZE 110*150*122(mm)
Specifications
- IMAGE SENSOR 640 * 480 CMOS
- LIGHT SOURCE 4PCS WHITE LED
SYMBOLOGIES
- 2D PDF417,Data Matrix,QRCode,Micro QR
- 1D
Code 128,UCC/EAN-128,AIM 128,EAN-8,EAN-13,ISSN,ISBN,UPC-E,UPC-A,
Interleaved 2 of 5,ITF-14,Matrix 2 of 5(European Matrix 2 of 5),Industrial
2 of 5,Standard 2 of 5,Code 39,Codabar,Code 93,Code 11,MSI-Plessey,
RSS-14,RSS-Limited,RSS-Expand etc.
- RESOLUTION 1D≥5mil 2D≥10mil
DEPTH OF FIELD
- EAN13 20mm-200mm (13mil)
- Code 39 10mm-100mm (5mil)
- QR Code 5mm-180mm (15mil)
PAYMENT
- CODE(PHOE)
- 20mm-450mm
- PCS 10%
- INTERFACE USB-HID ,USB-VCOM,UART(DUE TO ORDER)
MECHANICAL / ELECTRICAL
- SIZE 110*150*122(mm)
- WORKING MODE TRIGGER MODE , AUTO-SENSOR , CONTINUOUS SCAN
- WEIGHT 348g(WITH CABLE)
- INOUT VOLTAGE 5VDC±10%
CURRENT
- Operating:210mA±10mA;
- Standby:130±5mA;
ENVIRONMENTAL
- OPERATING TEMPERATURE 0°C to 45°C
- STORAGE TEMPERTURE -20°C to 60°C
- HUMIDITY 5%~90% (no-condensing)
- SHOCK RESISTANCE 1.0M FREE FALL TEST
CERTIFICATE
- CERTIFICATE FCC Part15 Class B,CE EMC Class B
VERSIONS OF SPECIFICATION
- VERSIONS V1.1
NOTICE:
Please make sure that the voltage meets the technical requirements when using the
scanner,
Do not shoot directly on your eyes during use.
Please protect the scanner if you may come into contact with corrosive, chemical and
other potentially dangerous, high-pressure and toxic substances.
Read the manual carefully before use to confirm the use environment.
All rights by shangchen, subject to change without notice
