Pre-orders Diamond UPS 20KVA online LED | D1890

Description

Model: MXG33 10-40kva

Diamond UPS 20KVA online LED

1. True double-conversion
2. Output power factor0.9
3. Input power factor correction
4. 50/60Hz Frequency Converter Mode
5. ECO mode energy saving
6. Emergency power off(EPO)function
7. Provides over voltage cut-off protection and surge immunity by MOV for full-time equipment protection
8. High power factor charger with very low ripple current when charging the battery
9. Low input THDi to reduce power system pollution
10. Adjustable output voltage &frequency on LCD panel
11. Smart battery charger design to optimize battery performance
12. Generator compatible
13. Optional HID Power Device USB Port

Pre-orders from 4-8 weeks

Mode	MXG3310K(L)		MXG3320K(L)		MXG3330K(L)	MXG3340K(L)
PHASE	3 phase with ground
CAPACITY	10KVA/9000W		20KVA/18000W		30KVA/27000W	40KVA/36000W
INPUT
Range of voltage(full load)	207~475Vac 3P4W+G
Range of frequency	40-70Hz(adjusted)
Power Factor	≥0.99 nominal voltage(100%load)
OUTPUT
Rated voltage	380Vac(1±1%)3P4W+G
frequency	1. The output frequency synchronizes with the input frequency when the input frequency is in the range of 46Hz~54 Hz. 2. The output frequency is 50Hz when the input frequency is not in the range of 40 Hz~46 Hz and 54Hz~60Hz. 3.BAT mode:50Hz.
Rated current	15A		30A		45A	61A
Power factor	0.9
Distortion	≤3%
Ratio	3:01
Over load	105%±5%<Load≤125%±5%60s transfer to bypass 125%±5%<Load<150%±5%30s transfer to bypass Load>150%±5%,300ms transfer to bypass
Line—bat transfer time	0ms
EFFICIENCY	>90%				>91%
BATTERY
Rated voltage	192Vdc (or 240Vdc)				+/-192Vdc (or +/-240Vdc)
Numbers	16(20)	16(20)×9AH	16(20)	16(20)×9AH	32(40)
Charging Current	5A	1A	7.5A	1A	5.5A
Size (L*W*H)mm	533*260*50​​1	560*260*717	710*260*717		710*260*717
Weight	26kg	72kg	57.5kg	98kg	58.5kg	62kg
Work temp.(℃)	0℃~40℃
Work humidity	20%～95%
Noise(dB)	≤60dB
