Description
Model: CM-RL1
Chungmei CM-RL1 Remote Indicating Lamp
Products Features
Remote Indicating Lamp
The conventional remote indicating lamp, CM-RL1, is designed to provide accurate remote indication for
use with CM conventional detectors.
Incorporating a red LED that is clearly visible when active, its primary use is to prevent any missing
alarm signal caused by separated zones such as closed or outside locked or inaccessible rooms.
- Plug-in type of Termination for ease of installation
- LED provided to indicate activation
- Parallel type wiring
- Low current consumption
Specifications
| MODEL NO. | CM-RL1 |
|---|---|
| POWER SOURCE | Power source from detector base |
| ALARM CURRENT | 12 mA |
| AMBIENT TEMP. | -10ยฐC ~ 55ยฐC |
| MATERIAL | Burning-proof plastics |
| WEIGHT | 28g |
| DIMENSIONS | 86(W) ร 86(D) ร 60(H) mm |
| COLOR | White |
