$ 185


  • 48 10/100/1000Mbps RJ45 ports
  • Innovative energy-efficient technology saves power consumption
  • Supports MAC address self-learning and auto MDI/MDIX
  • Standard 19-inch rack-mountable steel case
12-08-2022 4:30 PM

Model: TL-SG1048

48-Port Gigabit Rackmount Switch

Specifications

HARDWARE FEATURES
Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Interface 48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Physical Security Lock No
Power Supply 100-240VAC, 50/60Hz
Dimensions ( W x D x H ) 17.3 x 8.7 x 1.7 in. (440 x 220 x 44 mm)
Mounting 19" 1U Rack Mountable (Mounting bracket included)
Max Power Consumption 32.3W
Max Heat Dissipation 110.2BTU/h
PERFORMANCE
Switching Capacity 96Gbps
Packet Forwarding Rate 71.4Mpps
MAC Address Table 16K
Buffer Memory 12Mb
Jumbo Frame 12KB
Transfer Method Store-and-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents 48-Port Gigabit Rackmount Switch Power Cord Installation Guide Rackmount Kits Rubber Feet
Environment Operating Temperature: 0โ„ƒ~40โ„ƒ (32โ„‰~104โ„‰); Storage Temperature: -40โ„ƒ~70โ„ƒ (-40โ„‰~158โ„‰); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing
