TP-Link ES228GMP Omada Easy Managed Switch 28 Gigabit Ports with 24 PoE+ Ports | T215

$269.00

  • 26× RJ45 10/100/1000Mbps Ports (24× PoE+ compatible with 802.3af/at)
  • 2× Gigabit SFP Ports
  • 384W Total PoE Power, with up to 30W per PoE port*
  • Ease of Use: Supports plug-and-play for instant connectivity and additional features are easily configured
  • Centralized Cloud Management via the web or the Omada App
  • Up to 250m PoE distance**, QoS  , PoE Auto Recovery  , and Port Isolation for video surveillance networks

Available on backorder

Description

Model: ES228GMP

TP-Link Omada Easy Managed Switch 28 Gigabit Ports with 24 PoE+ Ports

Overview

  • 26× RJ45 10/100/1000Mbps Ports (24× PoE+ compatible with 802.3af/at)
  • 2× Gigabit SFP Ports
  • 384W Total PoE Power, with up to 30W per PoE port*
  • Ease of Use: Supports plug-and-play for instant connectivity and additional features are easily configured
  • Centralized Cloud Management via the web or the Omada App
  • Up to 250m PoE distance**, QoS  , PoE Auto Recovery  , and Port Isolation for video surveillance networks
  • Automatic Loop Prevention, VLAN, and IGMP Snooping
  • Rugged metal housing and rack-mountable design

Specifications

HARDWARE FEATURES
Interface • 24× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)
• 2× 10/100/1000 Mbps RJ45 Port
• 2× Gigabit SFP Slot
• Auto-Negotiation/Auto MDI/MDIX
Number of Fans 2
Facility Rackmountable
Physical Security Lock
Power Supply 100–240V AC, 50/60Hz
PoE ports (RJ45) • Standard: 802.3af PoE and 802.3at PoE+ compliant
• PoE Ports: 24 ports
• PoE Budget: 384W available for all PoE+ ports, 30W max per port
• Fast PoE & Perpetual PoE
• PoE Auto Recovery
• Up to 250m PoE transmission distance**
Dimensions 17.3 × 13.0 × 1.7 in.(440 × 330 × 44 mm)
Surge Protection ±6kV
PERFORMANCE
Switching Capacity 56 Gbps
Packet Forwarding Rate 41.67 Mpps
MAC Address Table 8K
Packet Buffer Memory 4 Mbit
Jumbo Frame 15 KB
SOFTWARE FEATURES
Quality of Service • Port-based/802.1p/DSCP QoS
• 8 Priority Queues
• Priority Schedule Mode
– WRR (Weighted Round Robin)
• Queue Weight Config
• Bandwidth Control
– Port-Based Rating Limit
• Storm Control
– Multiple Control Modes (kbps/pps)
– Broadcast/Multicast/Unknown-Unicast Control
L2 Features • Static Link Aggregation
• Loop Prevention / Loopback Detection
• Flow Control
– 802.3x Flow Control
• Mirroring
– Port Mirroring
– One-to-One
– Many-to-One
– Ingress/Egress/Both
• Port Statistics
– Port Mirror Status
– Traffic Statistics
• 802.1ab LLDP
L2 Multicast • IGMP Snooping
– IGMP v1/v2/v3 Snooping
– Fast Leave
VLAN • MTU VLAN
• Port-Based VLAN
• 802.1Q Tag VLAN
– Max 32 VLAN Groups
– 4K VID
Transmission Method Store-And-Forward
MANAGEMENT
Omada App Forks. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management • Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud access Forks. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Contactless provisioning Forks. Requires the use of Omada Cloud-Based Controller
Management functions • Web-based GUI
• DHCP Client
• Cable Diagnostics
• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Unified Configuration
Others
Certifications FCC, CE, RoHS
Package Contents • ES228GMP
• Power Cord
• Mounting Brackets
• Rubber Feet
• Screws
• Installation Guide
Environmental Factors • Operating Temperature: -5℃~45℃ (23℉~113℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
