TP-Link LS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+ | T19
TP-Link LS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+ | T19 - Image 2
TP-Link LS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+ | T19 - Image 3
TP-Link LS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+ | T19 - Image 4

TP-Link LS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+ | T19

$23.00

  • Full Gigabit Ports: Five gigabit augo-negotiationΒ ports provide up to 10 Gbps switching capacity.
  • 65 W PoE Budget: Four gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
  • Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
  • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices.
  • Plug and Play: Simply plug and play for instant connectivity with no configuration required.
  • Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.

Available on backorder

Categories: , ,

Description

Model: LS105GP

TP-Link 5-Port Gigabit Desktop Switch with 4-Port PoE+

Overview

  • Full Gigabit Ports: Five gigabit augo-negotiationΒ ports provide up to 10 Gbps switching capacity.
  • 65 W PoE Budget: Four gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
  • Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
  • PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices.
  • Plug and Play: Simply plug and play for instant connectivity with no configuration required.
  • Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.
  • Reliable Hardware Design:Β Durable metal casingΒ and desktop/wall-mounting design are well-suited for different environments.

Specifications

HARDWARE FEATURES
Interface β€’ 5Γ— 10/100/1000Mbps RJ45 Ports (Ports 1–4 supports 802.3af/at PoE+)
β€’ AUTO Negotiation
β€’ AUTO MDI/MDIX
Network Media β€’ 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ξ© STP (maximum 100m)
β€’ 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ξ© STP (maximum 100m)
β€’ 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m); EIA/TIA-568 100Ξ© STP (maximum 100m)
Fan Quantity Fanless
Installation β€’ Desktop
β€’ Wall Mounting
Power Supply External Power Adapter (Output: 53.5 VDC / 1.31 A)
PoE Ports (RJ45) β€’ Standard: 802.3 af/at compliant
β€’ PoE Ports: Ports 1–4, up to 30 W PoE output per port
β€’ Power Supply: 65 W
Dimensions ( W x D x H ) 3.9Γ—3.9Γ—1.0 in (99.8Γ—98Γ—25 mm)
Max Power Consumption β€’ 4 W (220/50 Hz. no PD connected)
β€’ 74.46 W (220/50 Hz. with 65 W PD connected)
Max Heat Dissipation β€’ 13.6 BTU/h (no PD connected)
β€’ 253.16 BTU/h (with 65 W PD connected)
PERFORMANCE
Switching Capacity 10 Gbps
Packet Forwarding Rate 7.44 Mpps
MAC Address Table 2K
Jumbo Frame 16 KB
SOFTWARE FEATURES
Advanced Features β€’ Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)
β€’ PoE Auto Recovery Button (Ports 1-4)
β€’ Compatible With IEEE 802.3af/at Compliant PDs
β€’ Mac Address Auto-Learning and Auto-Aging
β€’ IEEE 802.3x Flow Control
β€’ 802.1p/DSCP QoS
β€’ IGMP Snooping
β€’ Green Technology
Transfer Method Store-And-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents β€’ LS105GP
β€’ Power Adapter
β€’ Installation Guide
Environment β€’ Operating Temperature: 0–40 ℃ (32–104 ℉);
β€’ Storage Temperature: -40–70 ℃ (-40–158 ℉)
β€’ Operating Humidity: 10–90% RH non-condensing
β€’ Storage Humidity: 5–90% RH non-condensing
