Description
Model: SG105S
TP-Link 5-Port 10/100/1000Mbps Desktop Switch
Overview
- 5 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Steel housing, desktop or wall-mounting design
- Support 802.1p/DSCP QoSΒ and IGMP Snooping function
- Plug and play, no configuration needed
Specifications
| Standards and Protocols | IEEE 802.3i/802.3u/ 802.3ab/802.3x, IEEE 802.1p |
|---|---|
| Interface | 5 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports |
| Fan Quantity | Fanless |
| Max. Power Consumption | Maximum: 2.43W(220V/50Hz) |
| External Power Supply | External Power Adapter (Output: 9VDC / 0.6A) |
| LED | System Power Link/Act indicators per port built into each RJ-45 port |
| Dimensions ( W x D x H ) | 3.9 x 3.9 x 1.0 in. (100 x 98 x 25 mm) |
| Packet Forwarding Rate | 7.4Mpps |
|---|---|
| MAC Address Table | 2K |
| Packet Buffer Memory | 1Mb |
| Jumbo Frame | 16KB |
| Advanced Features | Green Technology 802.3X Flow Control 802.1P/DSCP QoS (for V2 and later version) IGMP Snooping |
|---|---|
| Transmission Method | Store and Forward |
| Certification | CE, FCC, RoHS |
|---|---|
| Package Content | 5-Port 10/100/1000Mbps Desktop Switch Power Adapter Installation Guide Rubber Feet |
| Environment | Operating Temperature: 0Β°C~40Β°C (32Β°F~104Β°F) Storage Temperature: -40Β°C~70Β°C (-40Β°F~158Β°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing |
