Model : TL-WR844N

TP-Link 300 Mbps Multi-Mode Wi-Fi Router

Overview

  • High-Speed Wi-Fi - 300 Mbps wireless transmission rate is ideal for both bandwidth sensitive tasks and basic work.
  • Boosted Coverage - Two omnidirectional antennas and 2×2 MIMO deliver strong Wi-Fi signal and reliable connections.
  • Multi-Mode 4 in 1 - Supports Router, Access Point, Range Extender, and WISP modes to meet any network need.
  • Parental Controls - Manages when and how connected devices can access the internet.
  • Guest Network -  Provides separate access for guests while securing the host network.
  • Smooth HD Streaming - Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming.
  • IPv6 Supported - Compatible with the IPv6 (the latest Internet Protocol version 6).

Specifications

WIRELESS
Standards Wi-Fi 4 IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds N300 2.4 GHz: 300 Mbps (802.11n)
WiFi Range 2 Bedroom Houses
2× Fixed Antennas
WiFi Capacity Legacy
Working Modes Router Mode Access Point Mode Range Extender Mode WISP Mode
HARDWARE
Processor Single-Core CPU
Ethernet Ports 1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports
Botones Reset Button
Power 5 V ⎓ 0.6 A
SEGURIDAD
WiFi Encryption WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x)
Network Security SPI Firewall Access Control IP & MAC Binding Application Layer Gateway
Guest Network 1× 2.4 GHz Guest Network
SOFTWARE
Protocols IPv4 IPv6
Parental Controls URL Filtering Time Controls
WAN Types Dynamic IP Static IP PPPoE PPTP L2TP
Quality of Service QoS by Device
NAT Forwarding Port Forwarding Port Triggering DMZ UPnP
IPTV IGMP Proxy IGMP Snooping Bridge Tag VLAN
DHCP Address Reservation DHCP Client List Server
DDNS NO-IP DynDNS
Management Tether App Webpage Check Web Emulator>
PHYSICAL
Dimensions (W×D×H) 4.5 × 4.2 × 1.0 in (115 × 106.7 × 24.3 mm)
Package Contents Wi-Fi Router TL-WR844N Power Adapter RJ45 Ethernet Cable Quick Installation Guide
OTHER
System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access)
Certifications FCC, CE, RoHS
Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power CE: <20dBm(2.4GHz) FCC: <30dBm
WiFi Reception Sensitivity 270M: -70dBm@10% PER 130M: -74dBm@10% PER 108M: -74dBm@10% PER 54M: -77dBm@10% PER 11M: -87dBm@8% PER 6M: -90dBm@10% PER 1M: -98dBm@8% PER
