UKS8104-RO 4-Port PS/2 KVM Switch Rack Mountable with OSD | A99

$110.00

  • 4-Port PS/2 KVM Switch Rack Mountable with OSD
  • Provides On Screen Display (OSD) menu for PC selection
  • Build-in extra daisy chain port and no waste any PC port
  • Support password protection and search PC name
  • Supports Microsoft Intellimouse , MicroSoft Intellimouse Explorer, Logitech Net Mouse, and the other Microsoft compatible mouse
  • Supports hot plug function for adding or removing PCs without powering down the KVM switch or PCs

Description

Model: UKS8104-RO

Stackable PS/2 KVM Switch

4-Port PS/2 KVM Switch Rack Mountable with OSD

Overview

The UKS8104-RO PS/2 KVM Switch is an electronic switching device for controlling four PCs from one PS/2 Keyboard, one PS/2 Mouse and one VGA Monitor. The KVM switch has complete keyboard and mouse emulation for simultaneous PCs boot-up process. To switch between PCs can be accomplished in two ways: through keyboard “Hot Key” commands or by using the convenient “Bank” and “Select” push button control.

The UKS8104-RO is specially designed with a daisy chain port that can be cascaded up to 8 levels with other rack mountable KVM switch including 4-port, 8-port, 16-port models. The build-in firmware supports On Screen Display (OSD) for naming and switching between multiple computers much easier.

The KVM switch provides the best convenience for users who have multiple desktop computers and/or notebooks; or power users who need control multiple servers from one console. It saves your equipment cost, time, space, power, and provides the best convenience of operation.

Features

  • Provides On Screen Display (OSD) menu for PC selection
  • Build-in extra daisy chain port and no waste any PC port
  • Support password protection and search PC name
  • Supports Microsoft Intellimouse , MicroSoft Intellimouse Explorer, Logitech Net Mouse, and the other Microsoft compatible mouse
  • Supports hot plug function for adding or removing PCs without powering down the KVM switch or PCs
  • Works with DOS, Win3.X, Win95 /98 /98SE /2000 /ME /XP, /NT, Netware, SCO Unix, HP UNIX, Linux
  • Provides console PS/2 to PC serial mouse conversion
  • Very high video quality – up to 1920 x 1440
  • High bandwidth: 200MHz
  • No software required – easy PC selection via push buttons or hot keys
  • Auto scan mode for monitoring PCs
  • Keyboard status restored when switching PCs
  • Buzzer sound for switching port confirmation
  • Uses inexpensive and commonly available cables
  • External power adapter
  • 19-inch rack mountable design

Specifications

System Specifications
PC Port 4
Console Port 1
Maximum PC Connections 116
LED Indicators One 7-segment LED for Bank, Two 7-segment LED for Port LED
PC Port Connector
(All Female Type)
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse mini Din 6 pin
VGA HDDB 15 pin
Console Port Connector
Daisy Chain Port Connector
(All Female type)
PS/2 Keyboard mini Din 6 pin
PS/2 Mouse mini Din 6 pin
VGA HDDB 15 pin
PC Selection On Screen Display, Hot Key, Push Button
On Screen Display Control Yes
Scan Intervals 5-99 seconds
Keyboard Emulation PS/2
Mouse Emulation PS/2
VGA Resolution 1920 x 1440
Bandwidth 200MHz
Daisy Chain and Levels Maximum to 8 levels
Weight 1.3kg
Dimension 410(L) x 165(W) x 44(H) mm, 19” Rack Mountable / 1RU Metal Case
Power Adapter 12VDC, 1A External Power Adapter
Emission FCC Class B, CE
Environment
Operating Temperature 0oC to 40oC (32oF to 104oF)
Storage Temperature -20oC to 60oC (-4 oF to 140 oF)
Operating Humidity 10% to 80% Non-Condensing
Storage Humidity 0% to 95% Non-Condensing
Storage Humidity 0% to 95% Non-Condensing
