Description

Model: Z-9001

Portable Data Collector

Z-9001 Series redefines simplicity with more simple features and less complicated options. Enhanced with the brand new, easy to use ZAC (ZEBEX Application Creator) program, Z-9001 Series allows users to achieve maximum efficiency through intuitive settings and user friendly interfaces. In addition, Z-9001 Series is uniquely shaped with a neat and rugged appearance to allow precision control with just one hand. Optimized to fit your needs, the Z-9000 Series comes with wide variety of scanning options, including 1D laser scan engine. Advanced features such as 32-bit CPU, wireless connection, status LED, and reliable IP53 seal are also included.

• Simple, easy to understand interface
• Transflective LCD for a wide working condition
• No programming background required

Specifications

OPERATIONAL

Interface: USB 2.0 full-speed device compliance

SYSTEM

CPU: 32 bit RISC ARM Cortex-M4 100MHz microprocessor

Memory: 8 MB Flash ROM, 4 MB RAM (8 MB optional)

Display: Mono FSTN, 128 × 128 dots graphic LCD with white back light

Scanner: 1D/2D decoding capability

Keypad & Button: Total 21 keys for full alpha/numeric input and system control keypads with LED back light

Software & Development: (a) Support the ZAC (ZEBEX Application Creator); (b) SDK to support C-Language compatible complier

PHYSICAL CHARACTERISTICS

Dimensions H x W x L: 132.0 × 59.0 × 29.0 mm

Weight (g): 157 g (battery included)

POWER

Main Battery: 1,150 mAh, 3.7V Li-ion rechargeable battery

Backup Battery: 15 mAh, 3.0V Lithium rechargeable battery

REGULATORY

Safety: FCC, CE, VCCI, BSMI

ENVIRONMENT & SAFETY

Operating Temperature: 0°C – 50°C (32°F – 122°F)

Storage Temperature: -20°C – 60°C (-4°F – 140°F)

Humidity: 5% – 95% RH (non-condensing)

Drop Durability: Designed to withstand 1.2M drops

Environmental Sealing: IP54 rated sealing

Tumble Resistance: 0.5M × 1000 times

ACCESSORY

Standard Accessory: Batch cradle, Li-ion battery, USB cable, power adapter, hand strap
