Description
Model: TL-POE200
TP-Link Power over Ethernet Adapter Kit
Overview
- Carries power & data over a single Ethernet cable up to 100 meters (328 feet) away
- 12VDC, 9VDC, or 5VDC selectable power output
- Plug-and-Play, requires no configuration
Specifications
| HARDWARE FEATURES | |
|---|---|
| Interface | For POE200AοΌ 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 LAN port 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 PSE port 1 48VDC power input portFor POE200B: 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 LAN port 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 PD port 1 12/9/5VDC power output port (5.5 mm round barrel) |
| LED Indicator | PWR |
| Dimensions ( W x D x H ) | 3.2 Γ 2.1 Γ 0.9 in. (81 Γ 54 Γ 24 mm) |
| OTHERS | |
|---|---|
| Power Supply Unit of PoE Injector | Input: 100~240VAC Output: 48V, 0.5A Switching PSU |
| Output Power For PoE Splitter | 12, 9, 5VDC selectable |
| Environment | Operating Temperature: 0β~40β (32β~104β) Storage Temperature: -40β~70β (-40β~158β) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
