$ 23


  • Carries power & data over a single Ethernet cable up to 100 meters (328 feet) away
  • 12VDC, 9VDC, or 5VDC selectable power output
  • Plug-and-Play, requires no configuration
24-11-2022 11:47 AM

Model: TL-POE200

TP-Link Power over Ethernet Adapter Kit

Overview

  • Carries power & data over a single Ethernet cable up to 100 meters (328 feet) away
  • 12VDC, 9VDC, or 5VDC selectable power output
  • Plug-and-Play, requires no configuration

Specifications

HARDWARE FEATURES
Interface For POE200A๏ผš 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 LAN port 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 PSE port 1 48VDC power input portFor POE200B: 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 LAN port 1 10/100Mbps Auto-Negotiation/Auto MDI/MDIX RJ45 PD port 1 12/9/5VDC power output port (5.5 mm round barrel)
LED Indicator PWR
Dimensions ( W x D x H ) 3.2 ร— 2.1 ร— 0.9 in. (81 ร— 54 ร— 24 mm)
OTHERS
Power Supply Unit of PoE Injector Input: 100~240VAC Output: 48V, 0.5A Switching PSU
Output Power For PoE Splitter 12, 9, 5VDC selectable
Environment Operating Temperature: 0โ„ƒ~40โ„ƒ (32โ„‰~104โ„‰) Storage Temperature: -40โ„ƒ~70โ„ƒ (-40โ„‰~158โ„‰) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
