TP-Link Archer C5400X AC5400 MU-MIMO Tri-Band Gaming Router

Wi-Fi Made for Gamers – Dominate the competition with WiFi made for gamers and gaming families
Battle-Tested Processing – 1.8 GHz 64-bit quad-core CPU, three co-processors and 1 GB RAM
Prioritized Performance – Set the QoS engine to gaming mode to keep your connection fast when everyone is online
Connect More Devices – Tri-band Wi-Fi speeds up to 5400 Mbps over one 2.4 GHz (1000 Mbps) and two 5 GHz (2167 Mbps) bands*
Adept Multi-Tasking – MU-MIMO and Airtime Fairness serve multiple connections and distribute Wi-Fi and optimize performance**

11-08-2022 9:48 AM

TP-Link AC5400 MU-MIMO Tri-Band Gaming Router

Wi-Fi Made for Gamers – Dominate the competition with WiFi made for gamers and gaming families
Battle-Tested Processing – 1.8 GHz 64-bit quad-core CPU, three co-processors and 1 GB RAM
Prioritized Performance – Set the QoS engine to gaming mode to keep your connection fast when everyone is online
Connect More Devices – Tri-band Wi-Fi speeds up to 5400 Mbps over one 2.4 GHz (1000 Mbps) and two 5 GHz (2167 Mbps) bands*
Adept Multi-Tasking – MU-MIMO and Airtime Fairness serve multiple connections and distribute Wi-Fi and optimize performance**
Far-Reaching Coverage – RangeBoost strengthens reception and beamforming sends targeted Wi-Fi to keep devices connected at farther distances than other routers*
Doubled Wired Speeds – Link Aggregation teams two of the eight Gigabit LAN ports or one LAN with the WAN port to double the connection speed
Comprehensive Security – Powerful antivirus works to protect all your devices from cyber threats with a free lifetime subscription of HomeCare^TM

WIRELESS
Standards	Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds	AC5400 5 GHz: 2167 Mbps (802.11ac) 5 GHz: 2167 Mbps (802.11ac) 2.4 GHz: 1000 Mbps (802.11n)
WiFi Range	4 Bedroom Houses 8× Detachable High-Performance Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage 4T4R Multiple streams in the same band strengthen the fault tolerance in transmission
WiFi Capacity	High Tri-Band Allocate devices to different bands for optimal performance 4×4 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients Airtime Fairness Improves network efficiency by limiting excessive occupation
Working Modes	Router Mode Access Point Mode

SECURITY
Network Security	SPI Firewall Access Control IP & MAC Binding Application Layer Gateway HomeCare™ Antivirus Malicious Site Checker Port Intrusion Prevention Infected Device Isolation Notification and Log
Guest Network	1× 5 GHz Guest Network 1× 2.4 GHz Guest Network
VPN Server	OpenVPN PPTP
WiFi Encryption	WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x)

HARDWARE
Processor	1.8 GHz 64 Bit Quad-Core CPU
Ethernet Ports	1× Gigabit WAN Port 8× Gigabit LAN Ports Static Link Aggregation (LAG) available with 2× LAN ports
USB Support	2× USB 3.0 Ports Supported Partition Formats: NTFS, exFAT, HFS+, FAT32 Supported Functions: Apple Time Machine FTP Server Media Server Samba Server
Buttons	Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button
Power	12 V ⎓ 5 A

SOFTWARE
Protocols	IPv4 IPv6
Service Kits	HomeCare™ Learn More>
Parental Controls	HomeCare™ Parental Controls Custom Profiles Content Filtering App Block URL Filtering Time Limit Time Schedule (Bedtime) Log Insight
WAN Types	Dynamic IP Static IP PPPoE PPTP L2TP
Quality of Service	GeForce NOW™ QoS QoS by Device HomeCare™ QoS QoS by Application
Cloud Service	Auto Firmware Upgrade OTA Firmware Upgrade TP-Link ID DDNS
NAT Forwarding	Port Forwarding Port Triggering DMZ UPnP
IPTV	IGMP Proxy IGMP Snooping Bridge Tag VLAN
DHCP	Address Reservation DHCP Client List Server
DDNS	TP-Link NO-IP DynDNS
Management	Tether App Webpage Check Web Emulator>

OTHER
System Requirements	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access)
Certifications	FCC, CE, RoHS
Environment	Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing

PHYSICAL
Dimensions (W×D×H)	11.3 × 11.3 × 7.2 in (288 × 288 × 184 mm)
Package Contents	Wi-Fi Router Archer C5400X Power Adapter RJ45 Ethernet Cable Quick Installation Guide
